sf::SimplePalette Class Reference

#include <SimplePalette.h>

Inheritance diagram for sf::SimplePalette:

Collaboration diagram for sf::SimplePalette:

Public Types
enum	Mode { ShiftRgb , ShiftHsv , ShiftHsl }
	Mode for generation of colors. More...

Public Member Functions
	Q_ENUM (Mode)
	SimplePalette (const Parameters &)
	Interface constructor.
void	addPropertyPages (PropertySheetDialog *sheet) override
	Overridden from base class.
ColorTable	getColorTable () const override
	Gets the color table of the implementation.
qreal	getCurveLevel (qreal x) const override
	Gets calculated level for color shifts.
Public Member Functions inherited from sf::PaletteInterface
	PaletteInterface (const Parameters &)
	Constructor for passing general structure for derived classes.
	~PaletteInterface () override=default
	Virtual destructor for derived classes.
virtual void	setSizes (qsizetype colorsUsed, qsizetype colorsSize)
	Sets the size of the color table of the implementation.
Public Member Functions inherited from sf::Persistent
	Persistent (QObject *obj)
	Constructor.
void	setSourceObject (QObject *obj)
QStringList	getProperties () const
	Gets the properties from the object as a string list to store as settings.
void	setProperties (const QStringList &) const
	Sets the properties of the object as a string list settings.

Properties
Mode	mode
QColor	colorFrom
QColor	colorTo
QColor	colorCenter
QString	formula

Additional Inherited Members
Protected Member Functions inherited from sf::Persistent
QMap< int, const char * >	getObjectProperties (const QObject *obj) const
	Gets a mapped property list af all properties of the object.
Protected Attributes inherited from sf::PaletteInterface
Parameters::Callback	_callback
qsizetype	_colorsSize {256}
qsizetype	_colorsUsed {_colorsSize}

Member Enumeration Documentation

Mode

enum sf::SimplePalette::Mode

Mode for generation of colors.

Enumerator
ShiftRgb
ShiftHsv
ShiftHsl

Constructor & Destructor Documentation

SimplePalette()

sf::SimplePalette::SimplePalette ( const Parameters &  )

explicit

Interface constructor.

Member Function Documentation

addPropertyPages()

void sf::SimplePalette::addPropertyPages ( PropertySheetDialog *  sheet )

overridevirtual

Overridden from base class.

Reimplemented from sf::PaletteInterface.

getColorTable()

ColorTable sf::SimplePalette::getColorTable ( ) const

overridevirtual

Gets the color table of the implementation.

Implements sf::PaletteInterface.

getCurveLevel()

qreal sf::SimplePalette::getCurveLevel ( qreal  x ) const

overridevirtual

Gets calculated level for color shifts.

Used in calculation of colors and drawing a curve when configuring.

Parameters

x	Value between 0.0 and 1.0.

Returns

Value between 0.0 and 1.0.

Implements sf::PaletteInterface.

Q_ENUM()

sf::SimplePalette::Q_ENUM

(

Mode

)

Property Documentation

colorCenter

QColor sf::SimplePalette::colorCenter

readwrite

colorFrom

QColor sf::SimplePalette::colorFrom

readwrite

colorTo

QColor sf::SimplePalette::colorTo

readwrite

formula

QString sf::SimplePalette::formula

readwrite

mode

Mode sf::SimplePalette::mode

readwrite

---

The documentation for this class was generated from the following file:

• SimplePalette.h
